The DWC30WIN is a highly efficient, compact, and lightweight switching power supply delivering outstanding performance. Designed to minimize noise specifically for communication purposes, it features a Noise-Offset control to eliminate any noise that may occur. This standard power supply also includes convenient features such as a voltage preset knob and a highly visible backlit meter.
1.Input voltage 220V AC
2.Output voltage 13.8DC adjusted voltage between 9.0 and 15.0 volts.Turn
clockwise to increase and counter clockwise to decrease the voltage.When
it is set at the center position it will supply 13.8 volts.
3.Output voltage regulation:less than 2%.
4.Protection Short-circuit,Automatic current limiting With in 30A.
5.Output current 30A (max),20A(continuous).
6.Ripple less than 80mVp-p at rated load.
7.fuse 5A.
8.Meter single volt/current meter,back-lit.
9.Dimensions:155 (W)x 70 (H)x 205 (D)mm (projections not included)
10.Weight approx.1.5kg
