General | |
FrequencyRange |
144-146&430-440MHz(EU CE
standard)* 144-148 &420-450MHz(Canada IC standard)* |
Memory Channel | 99 Groups |
Operation Voltage | DC7.4V ±10% |
Frequency Stability | ±2.5ppm |
Operating Temperature | -20℃ to+5℃ |
Mode of Operation | Simplex |
Antenna lmpedance | 50ohm |
Transmitter Part |
|
RF Owput Power | (VHF max)5W(UHFmax)4w |
FM Modulation | 11K0F3E@12.5KHz |
Adjacent Channel Power | 60dB @ 12.5KHz |
Transmision current | ≤1600mA |
Receiver Part | |
Receive Sensitivity | 0.25μV(12dB SINAD) |
Adjacent Channel Selectivity | ≥55dB@12.5KHz |
Inter Modulation and Rejection | ≥55dB@12.5KHz |
Conducted Spurious Emision | ≤57dB@12.5KHz |
Rated Audio Power Output | 1w @16 ohms |
Receive current | ≤380mA |
Rated Audio Distortion | ≤5% |
QYT Electronics Co., Ltd. (QYT) was one of the earliest professional two-way radio and accessories manufacturers in China, and now one of the top mobile radio providers as well. QYT is headquartered in Quanzhou, Fujian, China. We are mainly responsible for the company's related product hardware development, production, sales and engineering services. Our company also provides customized services as well as personalized, differentiated products (OEM/ODM).
